车用卷板机特点:
车用卷板机端部预弯时,能够自由地设定直边长度,上辊压下,在一定的压力下,实行高精度的端部预弯。车用卷板机由于连续弯曲,以及高精度的端部预弯,从而得到精度超群的制品;另外上辊呈鼓形状,托辊配合调节,从薄板到厚板这一广泛的范围内能够卷制理想的产品。
The uppe r rolle r can make ve rtical elevation o r ho rizontal shift The vertical elevation is hydraulic d riving,which is achieved by the action of the oil in the hydraulic cylinder on the piston;the horizontal shift is achieved th rough the torques from the lead sc rew cabinet,worm and the st ructure of screw and worm The lower roller only makes rotation,p roviding to rque fo r bending and rolling On the lowe r side of the lowe r rolle r,the re is support roller for adjustment The upper roller is in drum shape for enhancing the st raightness of the p roducts,The machine is fit bending va rious cylinde r bodies
车用卷板机参数:
规格型号
|
上辊加压力(Tops)
|
zui大板厚(mm)
|
板幅(mm)
|
上辊直径(mm)
|
动机(KW)
|
端曲
|
中央
|
驱动用
|
油压用
|
移动用
|
W11SNC-8×6000
|
1300
|
6
|
8
|
6000
|
450
|
15
|
7.5
|
4
|
W11SNC-8×8000
|
160
|
8
|
8
|
8000
|
480
|
15
|
7.5
|
4
|
W11SNC-8×9000
|
190
|
8
|
9
|
9000
|
520
|
17.5
|
7.5
|
4
|
W11SNC-10×6000
|
160
|
10
|
10
|
6000
|
460
|
18.5
|
7.5
|
7.5
|
W11SNC-16×6000
|
270
|
16
|
16
|
6000
|
520
|
30
|
11
|
7.5
|
W11SNC-20×6000
|
320
|
20
|
20
|
6000
|
550
|
37
|
15
|
11
|
由于产品在不断的改进中,如出现样本技术数据与产品实际数据有不一致处,应遵照双方的技术协义参数,不再另行通知!
